- Truelux LED Spotlight GU10
Description:
Product Name: TrueLux LED Spotlight Retrofit – MR16Application: Commercial Spot Light Retrofit
Wattage: 6W
LED Type: COB LED
Dimming Type:
Triac Dimming 0-100% Smooth Dimmable
(Philips NXP Dimming IC)
Match All Kinds Of Triac Dimmers Including
Leading Edge & Trailing Edge
Finishing: Pure Alluminum
Design Advantages: Patent Kulad Halogen Shaped Lens
Average Rated Life: 30000 Hrs
Power Factor: 0.75
Warranty: 3 Years
Technical Specs:
Beam Angle Options: 24°/ 36° / 60°
35W – 50W Halogen Equivalent
90% Energy Saving
Dimensions: 50mm(D)*58mm(H)
Dim to Warm Color:
2000-2700K / 2400-3000K
Same as Halogen Lamp
| Product Name | Input Voltage | Socket Base | Size | Dimmable | Wattage | Lumen | Equivalent | TC | Ra>90 | |||||
| Code | Angle | Code | Angle | Code | Angle | |||||||||
| Spotlight GU10 Non-Dimmable |
AC85-265V | Gu10 | 50mm(D)*58mm(H) | No | 5.5W | 400-420Lm | 50W Halogen | 2700K | G03NWHNI | 24° | G03NWHNJ | 36° | G03NWHNL | 60° |
| 400-430Lm | 50W Halogen | 3000K | G03NNHNI | 24° | G03NNHNJ | 36° | G03NNHNL | 60° | ||||||
| 450-480Lm | 50W Halogen | 4500K | G03HDHNI | 24° | G03HDHNJ | 36° | G03HDHNL | 60° | ||||||
| Spotlight GU10 Dimmable |
AC200-240V | Gu10 | 50mm(D)*58mm(H) | Yes All Kinds Triac Dimmers |
5.5W | 400-420Lm | 50W Halogen | 2700K | G03NWHYI | 24° | G03NWHYJ | 36° | G03NWHYL | 60° |
| 400-430Lm | 50W Halogen | 3000K | G03NNHYI | 24° | G03NNHYJ | 36° | G03NNHYL | 60° | ||||||
| 450-480Lm | 50W Halogen | 4500K | G03HDHYI | 24° | G03HDHYJ | 36° | G03HDHYL | 60° | ||||||
| Spotlight GU10 (Dim To Warm) |
AC200-240V | Gu10 | 50mm(D)*58mm(H) | Yes Dim to Warm All Kinds Triac Dimmers |
5.5W | 400-450Lm | 50W Halogen | 2000K-2700K | G03NXHYI | 24° | G03NXHYJ | 36° | G03NXHYL | 60° |
| AC90-130V | G03NXHYI-1 | 24° | G03NXHYJ-1 | 36° | G03NXHYL-1 | 60° | ||||||||
ac/dc
